Product Details
The LW700KV-T33 is a heavy-duty block-handling wheel loader purpose-built for demanding stone and aggregate applications. Designed with a high-strength frame, extra-wide fork assembly, and reinforced axles, it delivers superior lifting stability and structural durability in high-load scenarios. Powered by a reliable Weichai WP10H engine, the machine features a responsive pilot-assisted hydraulic control system that enhances operator precision and efficiency. Its extended lifting height, optimized weight distribution, and high-torque traction system enable safe, efficient handling of massive stone blocks, making it an excellent solution for quarries, bulk yards, and other intensive industrial environments.
LW700KV-T33
Model
33000kg
Rated Capacity
\
Bucket capacity
Wheel Loader XCMG LW700KV-T33 Key Specifications
| DESCRIPTION | SPECIFICATION |
| Rated Load Capacity | 33,000 kg (xugonggroup.com) |
| Rated Power | 178 kW (Weichai/QSM11 equivalent) |
| Operating Weight | Approx. 38,500 ± 300 kg |
| Fork Dimensions | ~1,500 × 1,504 mm |
| Max Lifting Height | 3,600 mm |
| Uninstall/Folded Height | 2,950 mm |
| Overall Dimensions (L×W×H) | ~9,310 × 3,275 × 3,650 mm |
| Wheelbase | 4,200 mm |
| Machine Weight | ~38,500 kg |
| Drive | Heavy-duty planetary drive axle |
| Hydraulic System | Pilot-assisted single joystick, Z-bar linkage, double rocker-arm |
| Cooling Fan | Electromagnetic clutch fan |
| Cab | Micro-pressurized cab with A/C and heating; adjustable steering column & seat |
| Dispatch Time | In-stock: within ~7 days; production: 15–20 business days |
| Annual Output Capacity | Up to ~500 units per year (T-series overall) |
Key Features for wheel Loader XCMG LW700KV-T33
High Load Capacity: 33 t lifting rated load at high mast configuration
Powerful Engine: 178 kW diesel engine-robust torque for heavy-duty stone/mine operations
Advanced Structure: Z-type linkage with double rocker arm ensures high digging & lifting force
Efficient Drive Line: Heavy-duty planetary axle with six-pair brake calipers for superior traction & reliability
Operator Comfort: Air-conditioned, micro-pressurized cab; pilot joystick & ergonomic controls
Enhanced Cooling: Electromagnetic clutch fan adjusts cooling as needed to save fuel and reduce noise
Application Scenarios for XCMG LW700KV-T33
Stone Quarries and Block Yards
Designed to transport oversized granite, marble, or basalt blocks with maximum safety and minimal risk of tipping.
Open-Pit Mining Sites
Capable of operating on rough, uneven terrain while carrying high-density materials such as ore or mineral slabs.
Port Terminals and Bulk Cargo Handling
Suitable for moving bundled stone materials or heavy pallets during vessel loading/unloading or storage transfer.
Our company
FAQ
Q: Can it operate in harsh terrain such as quarries or mining sites?
A: Yes, the LW700KV-T33 is designed with a reinforced frame, planetary heavy-duty axle, and enhanced traction, making it reliable in rough, uneven ground conditions.
Q: What is the standard fork size, and is it customizable?
A: Standard fork dimensions are 1,500 × 1,504 mm, suitable for most block handling needs. Custom fork sizes can be configured based on specific project requirements.
Q: How soon can the machine be delivered?
A: For standard models, dispatch is typically available within 15–20 business days, and in-stock units may be shipped even sooner.
