Product Details
The 3 Ton Telescopic loader with 7m or 10m lifting height is a compact yet powerful machine.It features advanced technology and an operator-focused design to ensure seamless operation on construction sites, warehouses and ports. Its smart design and durable structure meet global safety and emission standards, making it a top choice for a wide range of heavy-duty jobs."
Key Specifications-----The 3 Ton Telescopic loader with 7m or 10m lifting height
Pneumatic
Model
3000kg
Rated Capacity
4.25 m
Bucket capacity
Key Specifications
|
Description |
Unit |
Parameter value |
|
Max. capacity |
kg |
3000 |
|
Max. lifting height |
mm |
7000 |
|
Max. outreach |
mm |
3200 |
|
Overall length to carriage |
mm |
4650mm |
|
Length to face of forks |
mm |
5870mm |
|
Wheel base |
mm |
3150mm |
|
Ground clearance |
mm |
350 |
|
Tilt-up angle |
12 ° |
|
|
Tilt-down angle |
kN |
114 ° |
|
External turning radius(over tyres) |
4.25 m |
|
|
Total hydraulic cycle time |
s |
≤10.9 |
|
Unladen weight(with fork |
7600 kg |
|
|
Tires type |
Pneumatic |
|
|
Forks length/ width/ section |
1220 mm x 125 mm / 50 mm |
Key Features for telescopic mini loader
- Telescopic Boom for Precision
- Smooth hydraulic extension allows precise load placement, ideal for stacking, loading, and working in confined spaces.
- Enhanced Stability & Safety
- Robust chassis, stabilizers, and load-sensing hydraulics ensure safe operation even at full extension and maximum load.
- Durable Construction: Reinforced Z-bar linkage and Hardox 450 steel bucket ensure extended service life in abrasive conditions. Sealed heavy-duty axles and centralized lubrication system reduce maintenance needs.
- Operator Comfort & Control
- Ergonomic cab, intuitive joystick controls, and 360° visibility for easy operation, reducing fatigue during long shifts.
Optional Configurations for telescopic loader
- Attachments: Pallet forks, log grapple, rock bucket, and hydraulic hammer.
- Power Options: Standard diesel engine or hybrid/electric variants for eco-sensitive zones.
We worked on second hand construction machines more than 15 years, have rich stock for second hand wheel loader, check below details
Our company
FAQ
Q: Does it require outriggers/stabilizers for high lifts?
A: Outriggers are not needed for standard lifts (up to 7m), but mandatory for 10m lifts or uneven terrain to ensure stability.
Q: Is it available in diesel, electric, or hybrid models?
A: Primarily diesel-powered (meeting EU Stage V/EPA Tier 4 Final); electric models are custom-order only with 6–8 hours runtime.
Q: Can the boom operate while extended/retracted?
A: Yes, full hydraulic control allows lifting, lowering, and load placement at any extension length (7m or 10m).
Q: How does it perform on rough or sloped terrain?
A: Equipped with 4WD, differential locks, and optional tracks for mud/snow; max safe slope: 15° (unloaded) or 10° (loaded).
