4x4 Backhoe

Your Professional 4x4 Backhoe Supplier

Our goal is to become your true partner in the field of 4x4 backhoe in China. Fujian Raygoo Machinery Co., Ltd has always kept its professional role in wheel loader and other construction machinery industry. We offering reliable solutions to diverse industrial needs worldwide. We have a skilled engineering team dedicated to refining every stage, from product development and process improvement to production oversight, ensuring every product delivered meets rigorous quality and performance standards. The price is competitive and the product is quality-assured, which is a good choice for your long-term cooperation.

First 12 3 Last 1/3

Advantages of 4x4 Backhoe

Versatility:

Backhoe loaders can perform multiple functions, including digging, lifting, and transporting materials. This versatility reduces the need for additional equipment and saves time on the job.

Efficiency:

With their powerful engines and hydraulic systems, backhoe loaders can complete tasks quickly and effectively. This efficiency translates into lower labor costs and faster project completion.

Accessibility:

The compact size of mini excavators and small tractor loaders allows for better access to tight spaces, making them ideal for residential and urban projects.

Cost-effectiveness:

Investing in a backhoe loader can be cost-effective in the long run. Their durability and the availability of genuine parts ensure that your equipment remains reliable, reducing the risk of breakdowns and costly repairs.

Specification of 4x4 Backhoe

Description	Unit	Parameter Value
1. Overall Dimensions
Length × Width × Height	mm	6200×1960×2800
2. Wheelbase	mm	2550
3. Track Width	mm	1580
4. Minimum Ground Clearance	mm	290
5. Engine
Model		Yunnei YN38GBZ
Type		Turbochawzed, Four-Stroke
Rated Power	KW	76
Rated Speed	r/min	2400
Cylinder-Inside Diameter × Stroke	mm	4-102
6. Performance Parameters
System Pressure	MPa	18
Total Machine Weight	Kg	5400
Maximum Speed	Km/h	28
Maximum Gradeability	°	25
Minimum Turning Radius	mm	4500
7. Transmission System
Transmission Type		Fixed Shaft Power Shift
Number of Gears		Two Gears Ahead, Two Gears Astern
Torque Converter		ZL29Af
8. Steering System
Steering Type		Articulated, Fully Hydraulic Steering
Steering Angle	°	33
9. Bridge
Type		Wheel Side Reducer
10. Tires
Tire Model		16/70-20
Front Tire Pressure	KPa	250
Rear Tire Pressure	KPa	250
11. Braking System
Service Brake		Air Over Oil Caliper Brake
Parking Brake		Manual
12. Hydraulic System
Excavator Grab Digging Force	KN	28
13. Loading Parameters
Bucket Dumping Height	mm	3500
Bucket Dumping Distance	mm	900
Bucket Width	mm	2100
Bucket Capacity	m³	1.0
Maximum Lifting Height	mm	4300
Maximum Lifting Force	KN	42
Shovel Action Time	s	12

Types of 4x4 Backhoe

4x4 classic backhoe:

An all-wheel-drive system commonly found on older (but still relevant) models of backhoe loaders. The 4x4 drive system is powered by a traditional mechanical connection in which the drive wheels are engaged and disengaged using a shift lever — usually located inside the cab — and activated by a solenoid.

4x4 hybrid backhoe:

This combines the benefits of hybrid-electric technology and traditional combustion engines. In simpler terms, a hybrid machine is powered by both an internal combustion engine and an electric motor working together or separately. It can automatically switch between the two power systems to adapt to different operating conditions.

Features of 4x4 Backhoe

Standard features that significantly increase job efficiency include a wide field of vision, a big digging range, and a digging end side shift. Renowned turbocharged engine with powerful power, minimal noise, energy savings, and excellent efficiency. There are H-legs and A-legs that are aesthetically pleasing, have a high load capacity, and are extremely stable.

Application of 4x4 Backhoe

In construction in rural or mountainous areas, due to the complexity of the terrain, small excavators and loaders can more easily pass through narrow roads and rough terrain to complete tasks such as excavation, transportation and cleaning.

During the construction and restoration of urban green belts, small excavating loaders can be used to complete tasks such as soil excavation, tree planting, and stone transportation. Especially in parks and gardens, they can handle complex earthwork projects for greening.

Community construction and infrastructure: In the infrastructure construction of residential communities and commercial parks, the installation of water pipes, power lines and communication lines is carried out.

Packing and Shipping of 4x4 Backhoe

Lead Time	15-20 Working days
Shipping	Shipped by road, sea, rail

FAQ

Q: What kind of engine does a 4x4 backhoe have?

A: Most modern 4x4 backhoes have diesel engines. Due to their large size and scope of use, the horsepower of backhoe engines is generally greater than that of ordinary construction machinery. The power of the engine directly affects the excavation speed and efficiency.

Q: What is the relationship between 4x4 backhoes and horsepower?

A: A backhoe's horsepower is an important indicator representing the power of its engine. Backhoes with higher horsepower can handle more demanding tasks, operate faster, and have better adaptability in various terrains.

Q: What are the driving methods of a 4x4 backhoe?

A: Most 4x4 backhoes are two-drivings, such as single driving and double driving. In addition, some 4x4 backhoes are all driving, which means that the backhoe's wheels are all driven by the engine.

Q: What should you not do with a backhoe?

A: Starting in Gear: Anyone too near the wheels runs the risk of getting crushed.

Q: What is the difference between 2WD and 4WD backhoe?

A: For example, 2WD backhoe loaders are mostly used for landscaping and mulching. Whereas 4WD backhoes are able to work in unstable areas with rough ground, and they can carry much heavier buckets than 2WD backhoes. Digging depth is also a crucial component.

Q: Is it legal to drive a backhoe on the road?

A: Occasionally driving such equipment on a public road to reach or leave a construction site does not amount to furtherance of a transportation purpose.

Q: Is a backhoe considered an excavator?

A: A backhoe is a type of excavating equipment, or excavator, consisting of a digging bucket on the end of a two-part articulated arm.

We're professional 4x4 backhoe manufacturers and suppliers in China, specialized in providing high quality customized service. We warmly welcome you to buy cheap 4x4 backhoe from our factory.
