Product Details
The pre-owned Bobcat Skid Steer S300 is a highly flexible and durable machine, ideal for construction, landscaping, and agriculture. Known for its radial lift design (reaching up to 10.1 ft dumping height) and 74 HP engine, it balances power and efficiency
Key Specifications for Bobcat Skid Steer S300
| ategory | Specifications |
|---|---|
| Model | Bobcat S300 Skid Steer Loader |
| Brand | Bobcat (Manufactured in China for global distribution) |
| Engine | - Model: Kubota V3300-DI-T / V3800-DI-TE3 (variant by configuration) - Type: Turbocharged diesel, 4-cylinder, liquid-cooled - Power: 60 kW (81 HP) - Torque: 295 N·m @ 1,600 rpm - Displacement: 3.3 L / 3.7 L (depending on model year) |
| Operating Weight | 3,634 kg (standard) / 3,750–3,770 kg (high-flow configuration) |
| Rated Load Capacity | 1,361 kg (60% tipping load) |
| Tipping Load | 2,722 kg |
| Hydraulic System | - Standard Flow: 78.3 L/min - High-Flow Option: 116.2 L/min or 140 L/min (select models) |
| Travel Speed | 11.1 km/h (standard) / 19.1 km/h (dual-speed option) |
| Dimensions | - Length: 2.9 m (without attachment) - Width: 1.83 m (with bucket) - Height: 2.06 m - Wheelbase: 1.23 m |
| Lift Arm Path | Vertical lift mechanism (ensures precise material placement) |
| Tire Size | 12–16.5 inches (standard) |
| Fuel Capacity | 90.5 L |
| Hydraulic Pump | - Type: Gear pump - Max Pressure: 24 MPa |
| Cab Features | - ROPS-certified cab - 5-inch LCD dashboard - Ergonomic joystick controls - Air conditioning (optional) |
| Attachments | Compatible with 200+ attachments (e.g., buckets, snowplows, sweepers, trenchers, grapples) |
| Certifications | CE, TUV, ISO, RoHS |
Key Features for Used Skid Steer
Versatility with Attachments
Supports 200+ attachments, including buckets, snowplows, sweepers, and milling tools, making it adaptable to landscaping, mining, and municipal work
Optional high-flow hydraulic system (140 L/min) powers demanding tools like cold planers
Durability & Low Maintenance
Reinforced steel frame and sealed chain cases enhance longevity in harsh environments
SmartFAN cooling system reduces noise and engine wear, while an 87.1 L fuel tank extends operational uptime
Applications for Small Skid Steer
Due to its minimum turning radius being less than half that of similar articulated loaders, it is particularly suitable for operations in narrow areas such as urban infrastructure, roads or construction sites, factory workshops, warehouses, docks, ship decks and even ship cabins.
Optional Configurations for mini skidsteer
Angled Sweeper: For cleaning streets, parking lots, and public spaces.
Closed Sweeper: Enclosed design to minimize dust, ideal for indoor or sensitive areas.
Crushing Hammer (Breaker): For demolishing concrete, rocks, or masonry.
Vibratory Compactor: For soil, asphalt, or pavement compaction.
Milling Machine: For removing old road surfaces in preparation for resurfacing.
Snow Pusher/Snow Thrower: Winter maintenance; some models include ice breakers for icy conditions.
Our company
FAQs
Q: What causes low or no hydraulic pressure in the Bobcat S300?
A: Potential causes:
Faulty hydraulic pump (wear or seal failure).
Incorrect relief valve setting (pressure too low).
Air in the hydraulic lines (requires bleeding).
Clogged hydraulic filter (replace filter).
Solutions: Inspect the pump and relief valve, bleed air from lines, and replace filters (professional service recommended)
Q: What are the key steps for long-term storage (＞1 month) of the Bobcat S300?
A: For extended storage:
Clean the machine (remove mud/water) and check for loose fasteners.
Engine: Inspect coolant level (use 47% water + 53% propylene glycol mix, freeze point -37°C), oil level, and quality.
Hydraulic system: Check for leaks in motors, cylinders, and hoses; apply grease to exposed components.
Electrical system: Remove the battery (store indoors) to prevent discharge.
Monthly maintenance: Start the engine, idle for 5 minutes, then run at 1,400 RPM (≈2,300 rpm) for 5 minutes. Operate cylinders (extend/retract to 5–10mm short of max stroke) without load.
Q: What daily maintenance checks are required for the Bobcat S300?
A: Daily inspections should include:
Engine: Oil, coolant, and fuel levels.
Hydraulic system: Hoses, fittings, and cylinders for leaks; inspect cylinder rods for scratches.
Electrical system: Battery charge and wiring connections.
Tires/Tracks: Air pressure (tires) or track tension (tracks); check for wear.
Safety devices: ROPS (roll-over protection), FOPS (falling object protection), and seatbelt functionality.
