Product Details
This extendable boom skid steer is a high-performance tracked loader designed for superior stability, power, and versatility in demanding job site conditions. With an advanced tracked undercarriage, this machine offers excellent traction, making it ideal for construction, landscaping, agriculture, and heavy-duty material handling in rough or soft terrain.
Key Specifications
|
Description |
Unit |
Parameter Value |
|
Rated Load Capacity |
kg |
1,050 |
|
Bucket Capacity |
m³ |
0.5 |
|
Engine Power |
kW |
55 |
|
Hydraulic System Pressure |
MPa |
22 |
|
Max. Lifting Height |
mm |
3,600 |
|
Max. Dumping Height |
mm |
2,900 |
|
Wheelbase |
mm |
2,500 |
|
Track Width |
mm |
450 |
|
Operating Weight |
kg |
8,500 |
|
Hydraulic Cycle Time |
s |
≤7 |
|
Articulation Angle |
° |
42 |
|
Gradeability |
° |
35 |
|
Overall Machine Dimensions (L×W×H) |
mm |
7,600 × 2,400 × 3,300 |
Key Features for extendable boom skid steer
- All-Terrain Tracked Mobility：Built with a reinforced rubber track undercarriage, the loader ensures outstanding traction and ground contact. It performs reliably on soft, wet, or uneven terrain while minimizing surface damage - perfect for landscaping, forestry, and unstable ground.
- Superior Flexibility in Tight Spaces：Thanks to a 42° articulation design, this loader maintains exceptional agility - allowing for smooth turns and precise positioning even in confined job sites or irregular terrains.
- Track System Built to Last：The heavy-duty tracks are engineered for durability and grip, delivering stable movement across mud, sand, gravel, and slopes where wheeled machines might struggle.
Applications for boom skid steer loader
- Construction and roadwork
- Landscaping and agriculture
- Warehouse and logistics
- Municipal maintenance
Optional Configurations for boom skid steer
- Custom-Built Configurations：This telescopic boom skid steer can be tailored to diverse working conditions, offering multiple build options that align with specific industry needs - from urban infrastructure to remote forestry.
- Eco-Conscious, High-Performance Engines：Equipped with either Tier 3 or Tier 4 emissions-compliant powerplants, the machine delivers both regulatory compliance and dependable horsepower without compromise.
- Expanded Work Capabilities：Compatible with a broad suite of job-specific tools - including trenchers, snow blades, multi-purpose buckets, and forestry mulchers - it transforms easily from a loader to a multifunctional task machine.
- Advanced Undercarriage Choices：For differing terrain challenges, users can select from high-traction rubber tracks to minimize surface disruption, or steel-reinforced tracks built for aggressive environments like demolition or rock excavation.
Our company
FAQs
Q: What safety measures are there during the operation of the FSL75T skid loader?
A: The machine is equipped with a variety of safety devices, such as emergency stop buttons, safety guardrails, reversing alarms, etc. At the same time, the operator should strictly abide by the safety operating procedures during use to ensure the safety of himself and the surrounding personnel.
Q: Does the FSL75T skid loader meet environmental protection requirements?
A: The FSL75T skid loader adopts advanced engine technology and emission control measures, meets relevant environmental protection standards, and reduces pollution to the environment.
Q: Is there enough lighting for the machine to operate at night?
A: The FSL75T skid loader is equipped with a good lighting system, including work lights and headlights, which can provide sufficient light for night operations and ensure safe operation.
