Product Details
The Caterpillar Loader 980H is a proven heavy-duty machine engineered for demanding operations in earthmoving, quarrying and large construction projects. Designed for procurement teams looking for a reliable loader with a strong spec sheet, the 980H delivers best-in-class performance along with parts availability and fleet-scale value.
980H
Model
36,500kg
Operating Weight
4m3
Bucket capacity
Loader 980H Specifications
| Category | Specification | Value / Description |
| General Information | Model | Caterpillar 980H Wheel Loader |
| Manufacturer | Caterpillar Inc. | |
| Product type | Wheel Loader | |
| Production years | 2006 – 2012 (approx.) | |
| Engine | Engine model | Cat® C15 ACERT™ |
| Engine type | 4-stroke, 6-cylinder turbocharged diesel | |
| Displacement | 15.2 L | |
| Gross power (SAE J1995) | 293 kW / 398 hp | |
| Net power (ISO 9249) | 260 kW / 349 hp | |
| Rated speed | 1 800 rpm | |
| Maximum torque | 1 971 N·m / 1 454 lb-ft @ 1 200 rpm | |
| Cooling system | Water-cooled | |
| Emission rating | Tier 3 / Stage III A compliant | |
| Operating Specifications | Operating weight | 30 519 kg (67 294 lb) |
| Rated payload (standard) | 9 ton (approx.) | |
| Tipping load (full turn, ISO) | 19 496 kg (42 989 lb) | |
| Breakout force | 27 862 kg (61 425 lb) | |
| Bucket capacity range | 3.8 – 6.1 m³ (5.0 – 8.0 yd³) | |
| Dump clearance (at max height) | 3.2 m (10 ft 6 in) | |
| Reach at max lift | 1.5 m (4 ft 11 in) | |
| Cycle time (raise/dump/lower) | 11.5 seconds total | |
| Transmission | Transmission type | Powershift (planetary) |
| Number of gears | 4 forward / 4 reverse | |
| Max travel speed (forward) | 37 km/h (23 mph) | |
| Torque converter | Single-stage, 3-element | |
| Hydraulic System | Main pump type | Variable-displacement axial piston |
| Hydraulic flow (implement) | 464 L/min (122 gal/min) | |
| Relief pressure | 24 000 kPa (3 481 psi) | |
| Steering type | Load-sensing, articulated power steering | |
| Steering angle | ±35 degrees | |
| Dimensions | Overall length (bucket on ground) | 9.48 m (31 ft 1 in) |
| Width over tires | 3.22 m (10 ft 6 in) | |
| Height to cab top | 3.77 m (12 ft 4 in) | |
| Wheelbase | 3.70 m (12 ft 2 in) | |
| Ground clearance | 0.44 m (1.45 ft) | |
| Turning radius (outside) | 7.9 m (25 ft 11 in) | |
| Brakes & Tires | Service brakes | Hydraulic, wet-disc type |
| Parking brake | Spring-applied, hydraulic release | |
| Tire size (standard) | 29.5 R25 L3/L5 | |
| Capacities | Fuel tank | 479 L (126 US gal) |
| Hydraulic tank | 126 L (33 US gal) | |
| Cooling system | 75 L (19.8 US gal) | |
| Transmission oil | 60 L (15.9 US gal) | |
| Performance Features | Axle configuration | Front & rear planetary final drives |
| Differential | Limited-slip (optional) | |
| Drive system | 4-wheel drive (4×4) | |
| Operator controls | Joystick or pilot-hydraulic levers | |
| Cab | ROPS/FOPS certified, sound-insulated | |
| Air conditioning | Standard on most units | |
| Optional Configurations | Buckets | General purpose / rock / light material / coal |
| Tires | Bias or radial, various tread patterns | |
| Quick coupler | Available (factory or retrofit) | |
| Payload control system | Optional | |
| Rear-view camera | Optional | |
| Auto-lube system | Optional | |
| Cold-start package | Optional |
Applications
Quarrying and Aggregates – Ideal for loading crushed stone, gravel, and other bulk aggregates into trucks or hoppers.
Mining Operations – Suited for surface mining and stockpile management, handling overburden, ore, and processed materials.
Construction Projects – Reliable for site preparation, material handling, and backfilling operations on large infrastructure and road projects.
Port and Bulk Terminals – Used for loading and unloading bulk cargo such as coal, sand, or grain, supporting high-volume material movement.
Recycling and Waste Management – Efficient in handling construction debris, scrap, and recycled materials with dedicated waste-handling buckets.
Industrial Plants – Applicable for material handling inside cement, steel, and power plants where consistent cycle times and durability are key.
Rental and Equipment Fleets – A proven choice for fleet owners who prioritize durability, high resale value, and global parts availability.
Key Features for wheel loader 980h
Robust Structure – Heavy-duty frame, reinforced boom arms, and durable Z-bar linkage provide long structural life and excellent breakout force.
Advanced Transmission System – The planetary powershift transmission ensures smooth gear changes, high tractive effort, and reduced fuel consumption.
Operator Comfort & Safety – ROPS/FOPS-certified cab with low noise, adjustable seat, and wide visibility; optional rear-view camera and air-conditioning improve comfort and safety.
Efficient Hydraulic System – Load-sensing hydraulics automatically adjust flow for precise control, improving efficiency and reducing heat build-up.
Optional Configurations for caterpillar 980 h
Tires and Rims – A wide choice of bias or radial tires with various tread patterns for quarry, construction, or aggregate applications.
Quick Coupler System – Factory or retrofit coupler for faster attachment changes without leaving the cab.
Hydraulic Configurations – Optional third- and fourth-function hydraulics for operating specialized attachments.
Payload Control System – Integrated Cat Payload Control System (PCS) allows accurate weighing and load tracking to improve loading efficiency.
...
Our company
FAQ
Q: What is the resale value of the 980H?
A: Due to its proven reliability and brand recognition, the 980H maintains strong resale value compared with similar-class loaders.
Q: Can used Caterpillar 980H wheel loaders still be supported with parts?
A: Yes. Caterpillar maintains a strong global aftermarket and parts supply network, ensuring continued support for used units.
Q: What is the typical maintenance interval for the 980H?
A: Service intervals are generally every 250–500 hours, depending on operating conditions and fluid analysis results.
