Product Details
The FL966H Wheel Loader is a versatile and high-performance construction machine with the following key specifications and features:
Rated Load & Capacity:
Rated load: 6-9 tons (adjustable based on configuration)
Bucket capacity: 4.0 m³ (standard), with options for rock/quick-change buckets
Power & Engine:
Engine options: Weichai WD10G240E21 (178 kW) or Shangchai SC11CB240.1G2B1 (175 kW)
Fuel-efficient design with Euro III emission standards
Performance Metrics:
Max. traction force: 175 kN | Breakout force: 185 kN
Speed range: 0–38 km/h (forward) | Gradeability: 30%
Hydraulic transmission for smooth operation
Design & Comfort:
ROPS/FOPS-certified cab with UV-protection glass and panoramic visibility
Ergonomic controls and air-conditioning for reduced operator fatigue
Maintenance & Durability:
Single-layer radiator for easy cleaning | Extended service intervals
Lubrication points optimized for quick access
Dimensions & Weight:
Operating weight: 20,600 kg (standard) | Overall dimensions: 8,530 × 3,050 × 3,400 mm
FL966H
Model
6000kg
Rated Capacity
4m3
Bucket capacity
Wheel Loade FL966H Key Specifications
| Description | Specification |
|---|---|
| Operating weight | 20600kg |
| Transmission | Lovol wheel loader |
| Standard bucket capacity | 4.0 m² |
| Lift capacity (rated load) | 6,000 kg |
| Number of gears | 2 forward, 1 reverse |
| Maximum breakout force | 178 kN |
| Maximum travel speed | Forward: 38 km/h; Reverse: 17 km/h |
| Dimensions | |
| A. Overall length | 8530 mm |
| B. Wheel base | 3,200 mm |
| C. Ground clearance | 534 mm |
| D. Approach angle (back) | 30° |
| E. Overall height | 3,423 mm |
| F. Dump height | 3,040 mm |
| G. Overall operating height | 5,435 mm |
| H. Dump reach | 1,095 mm |
| I. Roll back angle (ground level) | 49° |
| J. Roll back (full height) | 450 mm |
| K. Track width | 2,250 mm |
| L. Machine width | 2,845 mm |
| M. Bucket width | 3,024 mm |
| N. Steering angle | 35° |
| Drive type | 4 wheel drive |
| Tyre dimension | 23.5-25 |
| Tyre pressure (Front) | 55-58 psi |
| Tyre pressure (Rear) | 46-49 psi |
| Service brake type | Air over hydraulic dry disc brake |
| Parking brake | Electric pneumatic drum brake |
| Service fill capacities | |
| Fuel | 260L |
| Hydraulic oil | 240L |
| Axles (main and final drives) | 2x26L |
| Engine | |
| Type | Watercooled, 4 stroke, 6 cylinders in line, direct injection, turbocharged |
| Model | Weichai WD10G220E23 |
| Rated power (SAE J1349) | 162 kW @ 2,000 rpm |
| Maximum torque | 980 Nm |
| Cylinder bore stroke | 126/130 mm |
| Transmission | 45L |
| Brake system | 4L |
| Hydraulics | Gear pump |
| Boom lift time | 5.7 sec |
| Total cycle time | 10 sec |
Key Features for wheel Loader FL966H
Power & Efficiency
Equipped with a high-torque Weichai/Shangchai engine (175–178 kW) for superior performance in heavy-duty operations.
Fuel-efficient design with optimized hydraulic systems, reducing operating costs.
Load & Performance
Rated load capacity: 6–9 tons (adjustable based on bucket type).
Standard bucket capacity: 4.0 m³, with options for rock, coal, or multi-purpose buckets.
Max. breakout force: 185 kN and traction force: 175 kN, ensuring strong digging and loading power.
Operator Comfort & Safety
ROPS/FOPS-certified cabin with air conditioning, low noise levels, and ergonomic controls.
Wide-view windows and LED lighting for enhanced visibility in low-light conditions.
Durability & Maintenance
Reinforced chassis & heavy-duty axles for long-term reliability in tough environments.
Easy-access service points and single-layer radiator for quick maintenance.
Versatility & Attachments
Compatible with forks, grapples, and snow pushers for multi-functional use.
Advanced hydraulic quick coupler for fast bucket/attachment switching.
Maneuverability & Stability
4WD drive system with excellent gradeability (30%) and max. speed of 38 km/h.
Optimized weight distribution (20,600 kg operating weight) for stability on slopes.
Optional Configurations for Lovol 6ton wheel loader
1. Bucket & Attachment Options
Rock bucket (reinforced for abrasive materials)
Coal/sand bucket (lightweight design for bulk materials)
Side dump bucket (for precise material placement)
Quick coupler (hydraulic system for fast attachment switching)
Pallet forks (for log/wood handling)
2. Performance Enhancements
Extended arm (increased reach for high-dump applications)
Desert/off-road tires (23.5-25PR or 26.5-25 sizes)
Third auxiliary hydraulic circuit (for specialized tools like grapples)
3. Operator & Safety Upgrades
ROPS/FOPS-certified cabin (with air conditioning)
Air suspension seat (reduced operator fatigue)
LED work lights (for low-visibility conditions)
4. Engine & Transmission
Euro III/V-compliant engines (Weichai/Shangchai, 162–175 kW)
Hydrostatic drive system (Linde, for smoother operation)
5. Specialized Use Packages
Arctic kit (cold-weather operation)
Noise reduction package (urban compliance)
Our company
FAQ
Q: What is the rated load capacity of the FL966H?
A: The FL966H has a rated load of 6,000 kg (6 tons) with a standard 4.0 m³ bucket, though configurations may adjust this to 3–6.5 tons depending on bucket type (e.g., rock/coal buckets) .
Q: What engine powers the FL966H, and what are its emissions?
A: It uses a Weichai WD10G240E21 engine (175 kW, 2200 rpm) with Stage II emissions (equivalent to Euro III). Key features include a three-stage air filter for dusty environments and multi-stage fuel filtration .
Q: What attachments are compatible with the FL966H?
A: Optional attachments include:
Rock/coal buckets (3.0–5.0 m³ capacity)
Pallet forks (for log handling)
Side-dump buckets (for precise material placement)
Quick coupler (hydraulic attachment switching) .
