Product Details
LW500FL is a classic 5-ton medium-duty front wheel loader developed by XCMG, optimized for construction sites, quarry, stockyard, port bulk cargo loading & earthmoving works. It owns reliable structure, strong breakout force and fuel-saving performance, widely popular in global construction machinery market.
LW500FL
Model
16500kg
Operating Weight
3m3
Bucket capacity
LW500FV Specifications
| Item | Parameter | Unit |
|---|---|---|
| Rated Load | 5000 | kg |
| Standard Bucket Capacity | 3.0 | m³ |
| Operating Weight | 16500 | kg |
| Max Dumping Clearance | 3100 | mm |
| Max Dumping Reach | 1274 | mm |
| Overall Dimension(L×W×H) | 8010×3016×3350 | mm |
| Wheel Base | 2900 | mm |
| Rated Engine Power | 162 | kW |
| Min Turning Radius(Bucket Outer) | 6920 | mm |
Applications
Large-scale earthmoving for construction, infrastructure or mining projects.
Quarry and mine site loading of rock, ore, coal, and bulk materials.
Material loading in bulk yards - hopper feeding, coal yard loading, ore stockpile handling.
Equipment fleet procurement for mining companies, construction contractors, aggregate suppliers and quarry operators looking for reliable, high-throughput wheel loaders for long-term heavy-duty use.
Core Advantages
Power & Digging Performance Equipped with reliable diesel engine, rated power 162kW, max breakout force 158kN and max traction force 156kN, powerful enough for hard soil, gravel and rock shoveling operation.
High-strength Heavy-duty Frame Box-type thick steel front/rear chassis design, anti-torsion and anti-impact, lengthen service life under severe working conditions.
Efficient Hydraulic System Load-sensing steering + dual-pump combined hydraulic circuit, low energy loss; boom lifting time ≤5.6s, total three-action cycle time ≤9.9s for fast loading circulation.
Flexible Mobility 2900mm standard wheelbase, compact turning radius (bucket outer:6920mm), adapts to narrow job sites; max travel speed up to 38km/h for quick site transfer.
Comfortable Driving Cabin Spacious sealed cab with optional air conditioner, low noise, humanized control layout to reduce long-hour operation fatigue.
Multi-purpose Option Standard 3.0m³ general bucket; can switch to log grapple, fork attachment, rock bucket to satisfy diversified working demands.
Our company
FAQ
Q: What is the rated load of LW500FL?
A: Its standard rated load is 5 tons (5000kg), operating weight is about 16500kg.
Q: What is the standard bucket size of this loader?
A: Equipped with 3.0m³ general bucket; rock bucket, fork or log grapple are optional attachments.
Q: How much fuel consumption per working hour normally?
A: Normal working fuel consumption is 10~15L/h, economical for sand, gravel and stockyard loading.
