Product Details
The XCMG 5.5 T Loader is a robust 5-ton class machine designed for demanding material-handling tasks. With a rated load capacity of 5,000 kg, bucket capacities from 2.5 to 4.5 m³, and a powerful 162 kW engine, this loader delivers high productivity for bulk handling, mining, quarrying, and large-scale construction operations. As a procurement decision-maker evaluating heavy wheel loaders, the LW500FV offers a compelling mix of performance, versatility and lifecycle value-an excellent choice for fleet procurement of a 5 ton wheel loader.
LW500FV
Model
17,065kg
Operating Weight
3m3
Bucket capacity
XCMG 5.5 T Loader Specifications
| Item | Specification |
|---|---|
| Model | XCMG LW500FV |
| Operating Weight | 16,900 kg (approx.) |
| Rated Load Capacity | 5,000 kg (5 Ton) |
| Bucket Capacity | 2.5 – 4.5 m³ (Standard 3.0–3.5 m³) |
| Engine Model | Weichai / Cummins (depending on configuration) |
| Rated Engine Power | 162 kW (≈ 220 hp) |
| Maximum Breakout Force | ≤ 170 kN |
| Dumping Height | 3,100 – 3,560 mm (depending on bucket type) |
| Dumping Reach | 1,100 – 1,200 mm |
| Transmission Type | Planetary Power Shift |
| Travel Speed (Forward) | 0–12 / 0–38 km/h |
| Travel Speed (Reverse) | 0–16 km/h |
| Steering Angle | 35° ± 2° |
| Minimum Turning Radius | 6,000 mm (bucket outside) |
| Hydraulic System Pressure | 18 MPa |
| Wheelbase | 2,900 mm |
| Wheel Track | 2,160 mm |
| Overall Dimensions (L×W×H) | 7,910 × 3,016 × 3,515 mm |
| Tire Size | 23.5-25 (heavy-duty grade) |
| Fuel Tank Capacity | 250 L |
Applications
Construction & Earthmoving Projects: Loading trucks, moving large volumes of earth or aggregate, where a 5-ton class wheel loader speed and capacity reduce overall project duration.
Mining & Quarry Operations: The combination of 5 ton rated load and high breakout force allows for effective shovel-load cycles in quarry faces or loading hoppers.
Bulk Material Handling & Ports: The LW500FV excels at loading/unloading materials such as coal, sand, gravel, ore or scrap in conveyor or stock-yard settings-making it a strong option when selecting a "bulk handling wheel loader".
Fleet Procurement for Rental or Multi-Site Deployment: Standardized size (5 ton class) means easier transport and deployment across multiple sites, efficient maintenance scheduling, and predictable lifecycle costs.
Key Features for xcmg 5.5 ton wheel loader
Operator Comfort & Serviceability
An ergonomically designed cab with low noise, optional heater/air conditioning, and well-accessible maintenance points support high operator productivity and minimize downtime. Easy serviceability is especially important in fleet procurement scenarios where uptime is critical.
Robust Drive & Frame Design
The drivetrain and frame employ a high-torque, high-efficiency chain and structural integrity adapted to heavy-duty sites. The strengthened front and rear frames, large section box beams and bearing joint hinge deliver stability and longevity under continuous operation.
.
Optional Configurations for xcmg 5.5 ton payloader
Reinforced rock bucket for quarry and mining conditions.
Side-dump bucket for confined loading environments.
Pallet forks for palletized cargo handling.
Log grapple and scrap grapple for forestry or recycling operations.
Heavy-duty rock tires or anti-skid tires depending on ground conditions.
Cold region package with engine and hydraulic pre-heaters.
High-temperature cooling package for continuous operation in hot climates.
Cab upgrades including air-suspension seat, rear-view camera, and ROPS/FOPS protection.
Centralized automatic lubrication system to reduce daily maintenance time.
...
Our company
FAQ
Q: How should I plan maintenance for the LW500FV?
A: Regular inspection of the hydraulic system, engine filters, lubrication points, and tire condition is recommended.
Many users choose the centralized automatic lubrication system to reduce daily maintenance workload.
Q: What factors affect fuel consumption during operation?
A: Fuel consumption mainly depends on bucket load weight, cycle time, ground conditions, operator handling practices, and job site layout. Consistent loading patterns and proper tire selection often reduce fuel usage.
Q: How does the LW500FV fit into fleet management planning?
A: As a 5-ton class loader, it offers a balance of bucket capacity, maneuverability, and transport convenience, which makes it suitable for multi-site operations, rental fleets, and standardized fleet deployment.
