Product Details
The LW400FV is a robust 4-ton wheel loader developed for high-efficiency loading and material transfer operations in construction, aggregate handling, municipal maintenance, and light mining applications. It features a durable frame structure and integrates a reliable Weichai powertrain with responsive load-sensing hydraulics, delivering solid breakout force, smooth gear transitions, and dependable performance on variable terrain. The operator cabin offers generous space, ergonomic layout, and excellent all-around visibility, ensuring both comfort and operational confidence. With streamlined maintenance access and a balanced design focused on fuel efficiency and longevity, the LW400FV is built to support intensive daily workloads with consistent productivity.
LW400FV
Model
4000kg
Rated Capacity
2.4m3
Bucket capacity
Wheel Loader XCMG LW400FV Key Specifications
| Description | Specification |
| Operating Weight | ≈15,800 ± 200 kg |
| Rated Load | 4,000 kg |
| Bucket Capacity | 2.0–3.0 m³ (standard: 2.3 m³) |
| Engine Model | Weichai WP7 or WP10 (≈7.5–9.3 L inline‑6) |
| Rated Power | 162 kW @ 2,200 rpm |
| Dumping Height | ≈3,050–3,200 mm |
| Max Breakout Force | ≈135 ± 5 kN |
| Max Traction Force | ≈125 kN |
| Wheelbase | ≈3,000 mm |
| Overall Dimensions (L×W×H) | ≈7,600 × 2,850 × 3,380 mm |
| Min. Turning Radius (bucket outer) | ≈6,000 mm |
| Travel Speed (F/R) | F1: 0–12 km/h, F2: 0–38 km/h; R1: max 16 km/h |
| Tyre Size | 20.5‑25 or optional 23.5‑25 |
Performance Highlights of the LW400FV
Optimized Powertrain
Equipped with a high-efficiency Weichai engine, the LW400FV delivers reliable power output and fuel economy, meeting the demands of mid-heavy-duty operations.
Efficient Hydraulic System
Load-sensing hydraulics ensure smooth, responsive operation with precise control and faster cycle times, enhancing worksite productivity.
Rugged Structural Design
Reinforced frame and key stress-bearing components are engineered for durability and strength, enabling long service life in harsh conditions.
Comfort-Focused Cabin
Spacious operator cabin features an ergonomic layout, low-vibration design, and wide visibility, providing a fatigue-free working experience.
Reliable Loading Capacity
With a rated load of 4 tons and a standard bucket volume of 2.3 m³, it strikes the right balance between maneuverability and capacity for a wide range of tasks.
Easy Maintenance Access
Centralized service points and wide-opening engine hood simplify daily inspections and upkeep, reducing downtime.
Optional Configurations for XCMG 4ton front end loader
We provide tailored attachment solutions to meet your specific operational needs for the bucket loader:
Bucket Variants
Multiple bucket options available including general-purpose buckets, high-capacity buckets, rock buckets, and light-material buckets to suit diverse working conditions.
Tire Choices
Standard 20.5-25 tires with optional upgrade to 23.5-25 for enhanced traction and durability on rough terrain.
Quick Coupler System
Enables fast and safe attachment changes, improving operational efficiency and versatility on the job site.
Hydraulic Fork Attachment
Suitable for pallet handling and logistics applications, expanding the loader's functionality beyond earthmoving.
(Additional attachments available upon request)
Our company
FAQ
Q: What is the bucket capacity range?
A: The standard bucket capacity is 2.3 m³, with optional buckets ranging from 2.0 to 3.0 m³.
Q: Is the operator cabin comfortable for long shifts?
A: Yes, the cabin is ergonomically designed with low vibration and wide visibility to reduce operator fatigue.
Q: How long does it take to dispatch the machine after order?
A: Typically, dispatch occurs within 10–15 business days for standard configurations.
