Product Details of the LG936F wheel loader
The LG936F Wheel Loader is a versatile and robust machine designed for efficient material handling in construction, mining, agriculture, and urban development. Combining high performance with reliability, it caters to diverse global operational needs. Below is a comprehensive overview of its specifications and features.
Key Specifications
| Parameter | Value |
|---|---|
| Operating Weight | 1500kg |
| Bucket Capacity | 0.95m³ |
| Rated Load | 5430 kg |
| Max. Dumping Height | 2,950 mm |
| Dumping Distance | 1,050 mm |
| Max. Tractive Force | 105 kN |
| Max. Breakout Force | 96 kN |
| Engine Power | 92 kW / 2,200 rpm |
| Fuel Tank Capacity | 140 L |
| Hydraulic Cycle Time | 9.2 seconds |
| Dimensions (L×W×H) | 6475*2135*2884 mm |
Core Features
Power & Efficiency
Engine: Equipped with a high-performance 6-cylinder diesel engine (92 kW) compliant with China II emission standards, ensuring strong power output and fuel efficiency
Transmission: Features a planetary transmission case with dual forward gears and one reverse gear, enhancing operational flexibility and durability. The hydraulic torque converter offers high transmission efficiency
Advanced Hydraulic System
Utilizes load-sensing full hydraulic steering and pilot-control hydraulics for precision handling, reducing operator fatigue and improving response speed
Double-sealed hydraulic pipelines enhance system reliability, minimizing leakage risks in demanding environments
Robust Structural Design
Reinforced Frame: Front/rear frames undergo 200,000-cycle fatigue testing, ensuring exceptional load-bearing capacity and stability
.Bucket Optimization: Protruding cutting-edge design with thickened anti-friction plates reduces resistance and boosts material retention
Operator Comfort & Safety
Enhanced Cab: Features a spacious steel cab with panoramic visibility, optional ROPS/FOPS certification, and air conditioning for all-weather comfort
Intelligent Dashboard: Digitized stepping dashboard enables intuitive monitoring and centralized electrical control for simplified maintenance
Versatile Applications
Ideal for farms, small-scale mining, timber processing, municipal projects, and construction sites due to its compact size and high maneuverability
Global Support & Warranty
Service: 1-year free online technical support and replacement parts
Global Reach: Distributed across 20+ countries (e.g., Russia, Australia, Vietnam) with localized dealer networks
Attachments
Our company
FAQ
Q: What is the maximum lifting capacity of the LG936F?
A: The LG936F has a rated operating load capacity of 3,000 kg (6,614 lbs) and a breakout force of ≥96 kN. Actual performance may vary slightly depending on bucket type (e.g., rock, coal, multi-purpose), material density, and ground conditions. Always adhere to load limits specified in the operator's manual.
Q: Does it comply with international emission standards?
A: Yes. The LG936F is equipped with a turbocharged, intercooled diesel engine (typically Yuchai/Weichai-based) compliant with China National Stage II (equivalent to Tier 2/Stage II). It delivers 92 kW (123 HP) at 2,200 rpm while balancing power and eco-efficiency. For markets requiring stricter norms (e.g., EU/EPA Tier 4), consult regional distributors for engine customization.
Q: How does its hydraulic system ensure efficiency?
A:
The loader features:
Load-sensing hydraulics: Prioritizes flow based on demand, reducing energy waste.
Pilot-control joystick: Enables precise bucket/arm movements with minimal effort.
9.2-second cycle time (shovel-to-dump), optimizing productivity in repetitive tasks. Regular maintenance (e.g., fluid checks at 500-hour intervals) is critical for sustained performance.
