Backhoe Loader Bhl75 Front Loader
The new generation K series backhoe loader features high flexibility, efficiency, reliability, and durability. The all-new visual identity appearance, panoramic cab, and optimized ergonomic design are applied to realize high fashion, beauty, and operation comfort. The multiple environmental adaptability technologies for high temperature, low temperature, highland, and heavy dust are available. The tool-less large-angle forward-tiltable hood realizes the one-stop maintenances and repairs. The diversified attachments, including four-in-one bucket, clamp, sweeper, breaking hammer, twist drill, and vibrating tamper, can be installed to realize multi-functionality.
Key Specifications
| BHL75 |
Specification |
Unit |
|
|
|
Loader Bucket Capacity |
m3 |
1 |
||
|
Excavator Bucket Capacity |
m3 |
0.26 |
||
|
Overall length |
mm |
7381 |
||
|
Overall width |
mm |
2280 |
||
|
Overall height |
mm |
3732 |
||
|
Total weight in travel |
kg |
7650 |
||
|
Engine Model |
|
QSF3.8 |
||
|
Engine rated power |
rpm |
74kW/1600 |
||
|
Engine rated torque |
rpm |
420Nm/1600 |
||
|
Driving speed |
km/h |
35 |
||
|
Maximum Digging Depth |
mm |
4332 |
||
|
Maximum Digging Height |
mm |
5370 |
||
|
Maximum Hinge Pin Height |
mm |
3478 |
||
Key Features
Key Performance for Backhoe Loader Bhl75 Front Loader
- Earthwork excavation and transportation: excavation, loading, backfilling, and leveling; suitable for site leveling, foundation excavation, and other infrastructure projects. Utilizes a front loader for topsoil stripping, bulk material handling, and site leveling.
- Agriculture and land reclamation: farmland irrigation construction (ditch digging, canal clearing), pasture clearing, and loading and unloading of agricultural supplies (fertilizer, feed). Adaptable to rural and field terrain, combining loading and excavation capabilities, making it a practical piece of equipment for farms.
- Municipal and road maintenance: municipal pipeline laying, sidewalk paving, road repair, and winter snow removal (requires a snowplow). Its relatively compact size (approximately 2.28 meters wide) and versatility are advantageous in space-constrained environments such as cities or suburbs.
Replaceable parts
Our company
FAQ
Q: What are its specific digging and loading capabilities, and can they meet my project needs?
A: Quantitative matching requirements: Its backhoe has a maximum digging depth of approximately 4.36 meters, and the loader's bucket capacity is approximately 1.0-1.2 cubic meters. It is suitable for small to medium-sized earthwork projects, farmland irrigation, and other scenarios. If the project requires deeper digging or extremely large handling volumes, a larger model should be considered.
Q: Can it truly be used for multiple purposes, saving costs and space?
A: Functional integration advantages: Yes, it integrates the core functions of a loader and a backhoe excavator. In single-site applications (such as from excavation and loading to backfilling and leveling) or in spaces with limited space (such as municipal streets), it eliminates the need for frequent relocation and rental of different equipment, effectively saving equipment costs, rental fees, and relocation time.
Q: Is it complex to operate? Is it comfortable for long-term operation?
A: Ergonomics and training: Modern backhoe loaders are designed with human-centered design in mind. Comfort can be assessed by checking whether it is equipped with an ergonomically adjustable seat, an intuitive control handle layout, good cab visibility, and an air conditioning system. It is easy to operate, but proper operation training is the key to ensuring high efficiency and safety.
