Product Details
This is 23HP Mini Skid Steer Loader, a compact ride-on wheeled skid-steer loader. Classified as micro-sized, multi-functional construction equipment, it is designed primarily for operations in confined spaces-such as courtyard renovations, indoor construction, livestock farming, landscaping, small-scale civil works, and debris removal in basements or corridors.
S490
Model
1200kg
Rated Capacity
0.12 M³
Bucket Capacity
Product Parameters
|
T490/S490 SEATED MINI LOADER |
|||
|
Name |
Factory Fast Delivery CE EPA Multu Function Ride-on Hydraulic Cylinder Wheeled/Tracked Seat Drive Diesel Mini Skid Loader |
||
|
Engine Model |
Rato R740/Briggs Stratton/Koop |
Maximum Operating Height |
2514mm |
|
Rated Power |
15kw |
Height to Bucket Pin |
1933mm |
|
Cylinders |
2 |
Total Height |
1872mm |
|
Intake Method |
Natural aspiration |
Bucket Flat Maximum Height |
2100mm |
|
Emission Standard |
EPA/EURO5 |
Total Length without Bucket |
2000mm |
|
Rated Load |
250Kg |
Total Length with Standard Bucket |
2644mm |
|
Maximum Load |
350Kg |
Unloading Height |
1429mm |
|
Maximum Lifting Force |
450KN |
Unloading Distance |
595mm |
|
Bucket Capacity |
0.12 m³ |
Bucket Rotation Angle on Ground |
27° |
|
Travel Speed |
0-6km/h |
Bucket Rotation Angle at Maximum |
34° |
|
Operating Weight |
1200KG |
Track Base |
925mm |
|
Working Pressure |
17-21bar |
Ground Clearance |
195mm |
|
Fuel Tank Capacity |
10L |
Length of Tail |
500mm |
|
Track Size |
18*8.5-8 |
Width of Vehicle |
1089mm |
|
Tire Size |
18*72 |
Bucket Width |
1050mm |
Mobility and Chassis Performance
1. Four-wheel drive skid-steer capability allows for zero-radius turns and agile maneuvering through narrow passages.
2. Travel speeds range from 0 to 6 km/h with two adjustable settings; deep-tread off-road tires provide excellent traction on muddy and gravel surfaces.
3. With a wheelbase of 940 mm, an overall length (including bucket) of 2,644 mm, and a width of less than 1.1 m, the machine easily navigates 1.2 m wide corridors and gateways.
4. Ample ground clearance ensures excellent mobility over uneven construction sites and unpaved rural paths.
Skid-Steer Loader Applications
Construction: Interior demolition and renovation, basement debris removal, and transport of sand and gravel on cramped job sites
Agriculture & Forestry: Manure removal in livestock facilities, transplanting nursery stock, and soil loosening and material handling in orchards
Municipal: Residential road maintenance, snow clearing, and small-scale trenching
Industrial Facilities: Short-distance loading and unloading of warehouse cargo and waste material cleanup
Our company
FAQ
Q: How wide is the DIGBOY skid steer loader? Can it fit through residential building corridors or into basements?
A: The machine's bare body width is under 1.1 meters, and the total width with a standard bucket is approximately 1.15 meters. It can easily navigate standard residential building corridors, indoor basements, and greenhouse aisles (wider than 1.2 meters). When fitted with narrow tires, it can access even tighter work areas, making it an ideal model for indoor use and confined spaces like courtyards.
Q: What attachments are available for this machine to enable multi-purpose functionality?
A:The machine features a standard front-mounted hydraulic quick-coupler, allowing for the rapid switching of over twenty types of attachments: standard buckets for basic earthmoving; hydraulic breakers for demolition; log grapples and trenchers for landscaping; snow sweepers for winter maintenance; pallet forks for warehousing and material handling; and manure buckets for livestock farms. A single unit covers a wide range of tasks, including handling, breaking, excavating, sweeping, and transplanting.
Q: What power options are available? Should I choose the gasoline or diesel model for indoor work?
A: Three versions are available: diesel, gasoline, and all-electric.
Diesel model: 19–24 horsepower; offers high torque and long runtime, making it suitable for prolonged, heavy-duty work at outdoor construction sites and farms.
Gasoline model: 25–26 horsepower; produces less exhaust and lower noise levels, making it suitable for villa courtyards and semi-enclosed indoor spaces.
Electric model: Zero emissions and silent operation; the top choice for basements and enclosed indoor renovation sites.
