SDLG LFT22H Wheel Loader Product Overview
The LFT22H is a heavy-duty wheel loader engineered by SDLG (Shandong Lingong), designed for demanding construction, mining, and material-handling operations. It combines robust structural integrity, fuel-efficient power, and operator-centric comfort to deliver high productivity in challenging environments.
LFT22H
Model
2200kg
Operating Weight
170kw
Engine Power
Technical Specifications of SDLG LFT22H Wheel Loader
| Parameter | Value |
|---|---|
| Rated Load Capacity | 22,000 kg |
| Operating Weight | 26,190 kg |
| Engine | Phase IV Compliant |
| Max. Breakout Force | 96 kN (approx.) |
| Turning Radius | 6,670 mm (outer wheel center) |
| Transmission | Heavy-duty planetary gear |
| Tire Size | 17.5-25 (standard) |
| Fuel Tank | 200 L |
Key Features & Technologies OF the SDLG LFT22H Wheel Loader
1. Heavy-Duty Structural Design
Reinforced Frame: Wide articulated frame with a center-mounted transmission shaft ensures uniform stress distribution and exceptional load-bearing capacity, ideal for heavy-material handling
Optimized Attachment System:Fork frame equipped with wear-resistant plates and thickened fork tips for enhanced durability
Strengthened bucket cylinder and vertical pivot-type lift cylinder enable a 22-ton lifting capacity at 1.8 meters
2. Powertrain & Efficiency
High-Performance Engine: Complies with China Phase IV emission standards, featuring a reinforced cylinder block, 4-valve technology, and optimized combustion for increased power output and fuel efficiency
Three-Mode Eco Switch: Standard P/S/E (Heavy/Medium/Light) modes adapt to varying workloads, reducing fuel consumption by up to 10%
Applications
Quarry & Mining: High load capacity for rock/ore transport.
Port Logistics: Efficient bulk-material handling.
Infrastructure Projects: Earthmoving, road construction, and heavy lifting.
Serviceability & Maintenance
Large-Access Hood: Wide-opening engine cover simplifies daily checks and repairs
Centralized Filtration: Air and fuel filters grouped on one side for efficient maintenance
Electric Fuel Pump: Eliminates manual priming after filter replacement
Our company
FAQ
Q:1. What is the maximum lift capacity and height of the LFT22H?
A:
Lift Capacity: 22,000 kg (at 1.8m height)
Max. Lift Height: 4.5m (with standard bucket)
Breakout Force: ≥96 kN Note: Capacity may vary with attachment types (e.g., forks reduce lift heigh
Q:Is the engine compliant with Tier 4/Stage IV emissions?
A:
Yes. The LFT22H uses a Phase IV-compliant engine (equivalent to Tier 4 Final/Stage IV):
4-valve design + optimized combustion
No DPF/SCR required (simpler maintenance)
Fuel consumption reduced by ≥8% vs. previous models.
Q: Can it operate in extreme cold (-30°C)? Any special configurations?
A:
Yes. Optional Arctic Package includes:
Engine block heater & insulated fuel lines
Cold-start batteries (-40°C rating)
Hydraulic oil with low-temperature viscosity (ISO VG 32) Requires dealer pre-order; not standard.
