SDLG LG953 Wheel Loader production:
LG953, a long-wheelbase loader for loading bulk materials and hard materials, features large breakout force and tipping load enjoyed by long-wheelbase loader as well as the flexibility and small turning angle enjoyed by short-wheelbase loader, and is widely applied in areas like sand plants, ports, construction sites, mines etc.
LG953
Model
17,000kg
Operating Weight
2.8m3
Bucket capacity
SDLG LG953 Specifications
| Parameter | Value |
|---|---|
| Bucket capacity(m³) | 2.8(2.4-4.5) |
| Operating weight(kg) | 16800 |
| Rated load(kg) | 5000 |
| Rated power(kW) | 162 |
| Length×Width×Height(mm) | 7920x3024x3423 |
| Wheel base(mm) | 3000 |
| Max.dumping height(mm) | 3080 |
| Dumping distance(mm) | 1105 |
| Steering angel(°) | 35 |
| Engine Model | Weichai WD10G220E21 |
| Emission standard | China Phase II |
| Max.tractive force(kN) | 152 |
| Max.breakout force(kN) | 175 |
| Gears() | Forward 2 reverse 1 |
| Total time(s) | 9.3 |
| Fuel tank capacity(L) | 260 |
Core Design & Performance Highlights:
1.Powerful and Efficient Powertrain: At its heart, the LG953 is equipped with a reliable Weichai WD10G220E21 engine that meets the China Phase II emission standard. This engine is characterized by low-speed and high-torque output, contributing to strong power delivery, high reliability, and low fuel consumption. The engine bay is fitted with a horizontally-mounted, two-stage air filter for enhanced protection and durability in dusty environments.
2.Advanced Thermal Management: A key feature of the LG953 is its optimized cooling system. It utilizes an electrically-controlled thermal energy management module and has undergone refinements to its radiator structure and air ducts. This advanced design effectively reduces the operating temperature of both the engine coolant and the hydraulic system oil, thereby enhancing overall cooling efficiency and machine reliability under heavy loads.
3.Robust Transmission and Chassis: The loader employs the technologically sophisticated SDLG planetary transmission system, which offers two forward gears and one reverse gear for easy and efficient operation. The drive axle is reinforced to handle substantial loading capacity. Furthermore, the loader's front and rear frames are reinforced and have undergone rigorous testing, including 200,000 cycles of fatigue intensifying tests, ensuring exceptional structural integrity and longevity.
characteristic:
1.. The loader is applied with the technologically-sophisticated SDLG planetary transmission with two forward gears and one reverse gear, enabling easy operation, good reliability and high efficiency; the drive axle is reinforced to provide large loading capacity and high reliability.
2.. The new steel cab applied offers for drivers a wide vision and a greater operating space, in which the full-coverage interioris configured to give a good sealing performance, and the optional A/C offers a good comfort.
3.. The digitalizedstepping instrument panel independently developed by SDLG is applied, offering an effective human-machine interaction.
SDLG LG953 Wheel Loader Features:
1.. The loader is equipped with the load-sensing mechanically-controlled hydraulic steering system, allowing easy control, and stable and reliableperformance. The hydraulic pipelines are of dual-sealing structure, further enhancing the tightness of hydraulic system.
2.. The loader is applied with the reinforced rear/front frames which have gone through 200,000 cycles of fatigue intensifying tests, and the load of complete loader is reasonably distributed, both of which contribute to a high loading capacity and a good stability.
3.. The optimal design is conducted for the implement, which ensures large breakout force and high full-load coefficient; the main cutting board of the bucket is of the trapezoidal wear-resisting steel structure, and the bottom wear-resisting plate is of thickened structure, which ensures small shoveling resistance and good wear-resisting property.
Our company
FAQ
Q: What is the bucket capacity and operating weight of the SDLG LG953?
A: The SDLG LG953 has an operating weight of 16,800 kg and comes with a standard bucket capacity of 2.8 cubic meters. Buckets within a range of 2.4 to 4.5 cubic meters are available to match different material densities and job requirements.
Q:What engine model does the LG953 use, and what are its emission standards?
A: This wheel loader is powered by a Weichai WD10G220E21 engine. This engine is certified to comply with the China Phase II (China II) emission standard, balancing robust performance with regulatory requirements.
Q: What are the key features of its cooling system?
A: The LG953 is equipped with an advanced cooling system featuring an electrically-controlled thermal energy management module. Combined with an optimized radiator structure and air flow ducts, this system is highly effective in reducing engine water temperature and hydraulic system oil temperature, thereby enhancing the machine's cooling efficiency and reliability during intensive work.
