Product Details
The XCMG payloader LW500FV is a 5-ton class heavy-duty loader widely used in quarry, mining, port handling, infrastructure, and aggregate operations. This unit is in original factory condition, not refurbished, not repainted, and without structural modification. The machine maintains its original components and working status, suitable for buyers who prefer authentic, unrefurbished equipment for direct operation or fleet expansion.
This model is recognized in the global market for stable performance, strong breakout force, and durable drivetrain configuration, especially equipped with a high-torque Weichai engine and XCMG original planetary transmission system.
LW500FV
Model
17,150kg
Operating Weight
3.0m3
Bucket capacity
xcmg payloader Specifications
| Item | Specification |
|---|---|
| Model | LW500FV |
| Engine Model | Weichai WP10HG230E476B |
| Engine Type | 4-stroke, Turbocharged, Intercooled |
| Rated Power | 169 kW (230 hp) |
| Rated Speed | 2200 rpm |
| Max Torque | 900 Nm @ 1400 rpm |
| Displacement | 10.5 L |
| Cylinder Bore/Stroke | 126 mm / 130 mm |
| Emission Standard | Stage II |
| Cooling System | Water-cooled |
| Fuel Tank Capacity | 280 L |
| Transmission Model | XCMG Original, Planetary transmission, 4 forward + 3 reverse |
| Maximum Speed | 38 km/h |
| Axle | XCMG Original, 2-wheel drive |
| Tires | 20.5-25 |
| Bucket Capacity | 3.0 m³ (struck) / 3.2 m³ (heaped) |
| Max Dumping Height | 3000 mm |
| Max Dump Reach | 1200 mm |
| Operating Weight | 16,500 kg |
| Overall Length | 7800 mm |
| Overall Width | 2740 mm |
| Overall Height | 3240 mm |
| Wheelbase | 3300 mm |
| Turning Radius | 6000 mm |
| Max Gradeability | 30% (17.5°) |
| Hydraulic System Pressure | 18 MPa |
| Lift Time (Boom) | 6.0 s |
| Bucket Dump Time | 1.5 s |
| Service Brake | Air-over-oil disc brakes |
Applications
Subgrade material loading
Gravel and crushed stone distribution
Asphalt plant material feeding
Road base preparation
Key Features for xcmg wheel loader zl50g
Reinforced front frame
High breakout force bucket linkage
Stable 3300 mm wheelbase
Optimized hydraulic system (18 MPa pressure)
3000 mm dumping height suitable for heavy trucks loading
Optional Configurations for xcmg 5 ton loader
Radial Tires: Provide improved durability and traction, suitable for hard surfaces or industrial applications.
Bias Ply Tires: Offer better performance in off-road conditions, suitable for rough terrains like quarries and mining.
Solid Tires: Ideal for handling sharp or heavy materials in tough operating environments.
Pneumatic Tires: Standard for general operations, offering a balance between comfort and performance.
High-Pressure Hydraulic System: Offers enhanced lifting force and faster cycle times, ideal for construction and material handling tasks.
Multipurpose Hydraulic System: Allows for the use of a variety of attachments, such as grapples or hydraulic hammers, expanding the loader's versatility.
...
Our company
FAQ
Q: Can the XCMG LW500FV be used for snow removal?
A: While not designed for snow removal, it can be equipped with appropriate attachments like snowplows or snow buckets for light snow handling in winter conditions.
Q: How do I maintain the hydraulic system?
A: The hydraulic system on the LW500FV should be inspected regularly for leaks, wear, and fluid levels. Ensure that hydraulic oil is changed as recommended by the manufacturer's maintenance schedule.
Q: Is the XCMG LW500FV suitable for rough terrain?
A: Yes, the LW500FV is designed to handle rough and uneven terrain, particularly when equipped with bias ply or solid tires. It is highly effective for use in quarries, mining operations, and rugged construction sites.
