Product Details
The SDLG LG956F wheel loader is a proven 5 ton front end loader widely used in construction, mining, quarry, and material handling applications. This fully refurbished unit is in excellent working condition, with comprehensive overhaul and replacement of key systems including hydraulic lines, engine components, hydraulic system parts, and cabin interior.
If you are searching for:
SDLG LG956 for sale
Used SDLG LG956 wheel loader price
5 ton wheel loader export
Refurbished SDLG LG956 loader
SDLG loader ready for shipment
This unit is available for inspection and fast international delivery.
LG956
Model
17,450kg
Operating Weight
3.0m3
Bucket capacity
SDLG LG956F Specifications
| Category | Specifications |
|---|---|
| Overall Dimension (L×W×H) | 8180×3024×3423 mm |
| Wheel Base | 3200 mm |
| Min. Ground Clearance | 534 mm |
| Max. Dumping Height | 3040 mm |
| Lifting Height | 4080 mm |
| Dumping Distance | 1095 mm |
| Dumping Angle | 45° |
| Bucket Rollback at Ground Level | 43° |
| Wheel Tread | 2250 mm |
| Steering Angle | 36° |
| Horizontal Crossing Radius | 7230 mm |
| Min. Turning Radius | 6325 mm |
| Bucket Capacity | 3.0 m³ |
| Rated Load | 5000 kg |
| Operating Weight | 17450 kg |
| Max. Tractive Force | 165 kN |
| Max. Breakout Force | ≥175 kN |
| Tipping Load | 2110 kN |
| Engine Model | WD10G220E23 |
| Engine Type | Inline, water-cooled, direct injection, dry cylinder liner |
| Rated Power | 162 kW |
| Rated Speed | 2000 r/min |
| Engine Displacement | 9726 ml |
| Cylinder Bore/Stroke | 126/130 mm |
| Max. Torque (N·m) | 960 N·m |
| Emission Standard | GB 20891-2007 (China Phase II) |
| Min. Fuel-Consume Ratio | 215 g/kW·h |
| Transmission Type | Planetary power shift |
| Torque Converter | Single-stage four-element double-turbine hydraulic torque converter |
| Gears | Forward 2, Reverse 1 |
| Speed at Forward Gear I | 0-13 km/h |
| Speed at Forward Gear II | 0-38 km/h |
| Speed at Reverse Gear I | 0-17 km/h |
| Hydraulic System Type | Hydraulic pilot control |
| Total Time | 510.08 |
| Service Brake Type | Air over hydraulic disc type |
| Parking Brake Type | Electric pneumatic internal expansion shoe type |
| Steering System Type | Load sensing full hydraulic articulated steering |
| System Pressure | 16 MPa |
| Fuel Capacity | 260 L |
| Hydraulic Oil Capacity | 240 L |
| Engine Oil Capacity | 20 L |
| Transmission Oil Capacity | 45 L |
| Drive Axle Oil Capacity | 2x26 L |
| Braking System Oil Capacity | 4 L |
Applications
Quarry stone loading
Mining material handling
Sand and gravel yards
Construction site loading
Road construction projects
Port cargo handling
Agricultural bulk material operations
Key Features for l956f wheel loader
Cost-effective alternative to new wheel loader
Strong availability of spare parts worldwide
Simple mechanical structure, easy maintenance
High resale value
Suitable for export markets in Africa, South America, Southeast Asia, and Middle East
Engine System
Complete engine inspection and servicing
Replacement of worn internal components
Fuel system calibration
New filters and seals installed
Stable idle and strong output performance
Hydraulic System
Hydraulic pumps inspected and tested
Replacement of hydraulic pipelines and hoses
Hydraulic oil system cleaned and renewed
Cylinder seals replaced where required
Smooth lifting and dumping operation
Transmission & Powertrain
Transmission system checked and calibrated
Axles inspected and serviced
Drive system tested under load condition
Electrical System
Wiring harness inspection
Battery replacement if required
Lighting system fully functional
Cabin & Interior
Interior panels refurbished
Seat replaced or renewed
Dashboard instruments tested
Clean and comfortable operator environment
Structural Components
Frame checked for cracks or structural stress
Reinforced welding points inspected
Fresh paint after surface treatment
This is not a simple repaint unit. The machine has been mechanically restored and performance-tested before delivery.
Optional Configurations for lg956l wheel loader
Protection & Durability Packages
Heavy-Duty Guarding Package
Engine compartment protective screens
Axle and underbody guards
Hydraulic hose protection
Extended Warranty & Service Plan
Cold Climate Package - Heated battery, insulated hydraulic lines
📡 Monitoring & Control
Telematics Tracking System
GPS location
Operating hours tracking
Remote diagnostics
Advanced LCD Display - Clearer machine status readouts
🌍 Export & Regional Compliance
Shipping Preparation Kit
Export packing
Container fastening points
Regional Regulation Compliance Kits (as required per destination country)
...
Our company
FAQ
Q: Is this SDLG LG956 fully refurbished?
A: Yes. The engine, hydraulic system, pipelines, transmission components, and cabin interior have been thoroughly inspected, serviced, and replaced where necessary.
Q: Can this SDLG LG956 be exported?
A: Yes. The machine is available for international shipment and can be prepared for container or bulk cargo loading.
Q: What is the dumping height of SDLG LG956?
A: Maximum dumping height is approximately 3,100 mm.
